• Record

Video compress: H.264 baseline /main profile @Level 1-4.2

Resolution: 4CH AHD 1080p @30fps + 4CH IPC 1080p @30fps

Audio compress: 2CH G.711 8K/16bits

Record mode: Full record / Parking record



• Playback

Total:1080p @120fps

Ex: 4CH AHD 1080p @30fps + 4CH IPC 1080p @30fps



• Search mode: time index / time direct / Event
• Video input: Aviation x 4 + IPC x 4
• Video output: RCA x 1 / VGA x1 / HDMI x1 (1920x1080)
• Audio input: RCAx 2
• Audio output: RCAx1 / HDMIx 1
• Live Display Split:  1 / 4 / 9
• Video Channel Swap: Yes
• Menu:GUI setup menu
• Control: IR / Mouse
• LED indicate: Front panel 2 LED indicate (Power / Run)
• Storage: 2.5" SATA3 x1 (MAX: 2TB), SDxC *1 (MAX: 128G)
• Backup: USB 2.0 / Network
• Ethernet: RJ45 10M/100M  x1 + 4PON for internet IPC connection
• Optional Network: 3G/ 4G / Wifi
• Alarm Input: 4 CH
• Alarm Output: 2CH TTL output
• Support: GPS / G-Sensor / Car speeding pulse in / Buzzer / RTSP / Temperature sensor / Car Voltage Detect
• Optional Support: TPMS / RS485 (PTZ  Pelco - P / D)/ RS232
• Language: Multi Language
• Administrable password: Two level password for System & Storage format
• System fail report: Temperature / HDD / SD / Voltage / GPS / G-sensor

• Boot delay: 0 ~ 10 sec
• Power Loss Protection: 3 ~ 5 sec
• Power Control : DC12V @3A output (independent fuse)
• Power in: DC9 ~ 36V
• Power consumption: 8.4W
• Operation Temperature: -25°C - +70°C



Software

• PC playback viewer: playback SD/HDD records under non-network process
• VMS - CarGisplayer (Optional): server / client remote viewer
• Mobile APP - Guard VMS (Optional): iOS / Android client remote viewer / Event Message / Push Video
